10 VA-4 - Technical Specifications

5 Technical Specifications

INPUTS: 2 balanced stereo, up to 16dBm/33kΩ on female XLR

connectors

OUTPUTS: 2 balanced stereo, up to 21dBm/50Ω on male XLR

connectors

BANDWIDTH (-3dB): >100 kHz

S/N RATIO: 80dB@6dB Gain (unweighted)

CROSSTALK (all hostile): 74dB@1kHz; -68dB@20kHz

CONTROLS: Level Control and Channel Selection, Impedance

selection

COUPLING: AC at output

AUDIO THD + NOISE: 0.02%@1kHz

AUDIO 2nd HARMONIC: 0.008%@1kHz

OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE: -40° to +70°C (-40° to 158°F)

HUMIDITY: 10% to 90%, RHL non-condensing

DIMENSIONS: 19” x 7” x 1U (W, D, H)

WEIGHT: 2.5 kg. (5.5 lbs.) approx.

ACCESSORIES: Power cord, Null modem adapter, Windows®-based

control software

OPTIONS:

Specifications are subject to change without notice at http://www.kramerelectronics.com
